Omni Type-27 plastic manual valves are the economical choice for reliable fluid flow control. These one-piece valves feature a molded body design with hyperbolic flow characteristics, ensuring low pressure drops and secure sealing. While they are primarily used in on/off applications and are excellent for use in clean fluid service applications with very little to no suspended solids. With a compact, low-profile design, unibody sealed carrier construction, and short face to face dimension, these valves provide excellent performance. Equipped with 2-stem O-rings, PTFE seats with elastomeric backing, and an ergonomic handle design, they offer convenience and durability. These valves also boast a full vacuum service rating, full port opening, and the ability to accept a molded ISO top flange for actuation mounting. Suitable for a wide range of fluid flow applications, the Omni Type-27 plastic manual valves are the ideal choice for reliable and efficient aquaculture operations.
FEATURES
- 2-way blocking valve
- Compact, low profile
- Unibody sealed carrier construction
- Short face to face dimension
- 2-Stem O-rings
- PTFE seats with elastomeric backing
- Ergonomic handle design
- Full vacuum service rating
- Full port opening
- Accepts molded ISO top flange for actuation mounting
TYPICAL APPLICATIONS
- Recirculating Aquaculture Systems
- Water & Wastewater Treatment Aeration & Mixing
- Living Exhibits
- Research
- Holding tanks
- Public Aquariums
