There are two optional pH sensing versions available, HF and LC. The HF version is for applications where traces of hydrofluoric acid (2% or less) will attack standard pH glass. The LC version can be used for low conductivity fluids 20-100µS/cm nominal.
The 2742-2726 electrodes incorporate o-ring seal for use with 1/2" to 4" GF installation fittings. They can also be mounted directly into reducing tees, DN20 to DN100 (3/4" to 4"). Sensor tip must be in flow path.
Features
- Patented reference design for exceptional performance and prolonged life
- UHMW polyethylene reference junction
- Memory chip enabled for access to a wide range of unique features when connected to the 751 pH/ORP Smart Sensor Electronics
- PPS body for broad range of chemical compatibility
- Patented DryLoc® connector with gold plated contacts
- Special design allows for installation at any angle, even inverted or horizontal
- Mounts in GF standard installation fittings from DN20 to DN100 (3/4" to 4")
- Quick temperature response
- Bulb and flat HF resistant glass available for trace HF, in less than 2% concentration applications
- Low conductivity sensor available for liquids from 20-100µS/cm
Applications
- Monitoring
- Industrial Water Treatment
- Municipal Water Treatment
- Aquaculture
- Aquatic Life Support System
- Agriculture
- Water Parks
